Outdoor Distribution Panels are robust enclosures designed to house and protect electrical components and circuits used for distributing power in outdoor environments. These panels are constructed from durable materials that withstand exposure to weather elements such as rain, snow, UV radiation, and temperature variations. Outdoor Distribution Panels typically house circuit breakers, fuses, and other protective devices to ensure safe and reliable power distribution to outdoor equipment, lighting, or facilities. They are commonly used in applications such as outdoor lighting systems, parks, construction sites, and industrial facilities where electrical distribution needs extend beyond indoor environments. Outdoor Distribution Panels facilitate safe and efficient electrical distribution outdoors, providing protection against environmental factors while ensuring continuity of electrical supply to support various outdoor activities and operations.
Invent Controls Private Limited offers robust Outdoor Distribution Panels designed to efficiently distribute electrical power in outdoor environments while ensuring reliability and safety. Our panels are engineered with weather-resistant materials and durable construction to withstand various climatic conditions, making them ideal for applications in industries such as telecommunications, construction sites, and outdoor events. Outdoor Distribution Panels from Invent Controls provide reliable protection and control for electrical circuits, ensuring uninterrupted power supply even in challenging outdoor settings.
Each Outdoor Distribution Panel is customizable to meet specific client requirements, offering flexibility in configuration and capacity. These panels are equipped with advanced features such as circuit breakers, surge protection, and metering options, ensuring efficient power distribution and management. Invent Controls prioritizes quality and innovation, adhering to industry standards to deliver panels that optimize energy usage and enhance operational efficiency in outdoor installations. Trust Invent Controls Private Limited for Outdoor Distribution Panels that combine durability, performance, and safety to meet the demands of diverse outdoor applications.
Special Features of Invent Controls Private Limited Outdoor Distribution Panel Boards
Invent Controls Private Limited offers robust Outdoor Distribution Panel Boards, designed for reliable power distribution in outdoor environments. Here are the key features:
Weatherproof Construction: Our outdoor distribution panels are built with weatherproof materials and enclosures, ensuring durability and protection against environmental elements such as rain, dust, and UV radiation.
High-Quality Components: Designed with high-quality electrical components, our panels maintain reliable performance in varying weather conditions, including extreme temperatures and humidity.
Customizable Configurations: We provide customizable configurations to meet specific outdoor installation requirements. Whether for utility substations, industrial sites, or outdoor events, our panels can be tailored to accommodate different voltage ratings and distribution needs.
Safety and Security: The panels include robust safety features such as circuit breakers, surge protection devices, and secure locking mechanisms to prevent unauthorized access and ensure safe operation.
Easy Installation and Maintenance: Designed for ease of installation and maintenance, our panels feature accessible components and clear labeling for quick identification and troubleshooting. This minimizes downtime and enhances operational efficiency.
Remote Monitoring Capabilities: Optional remote monitoring capabilities enable operators to monitor panel status and performance remotely, facilitating proactive maintenance and minimizing site visits.
Space-Efficient Design: Despite their rugged construction, our outdoor distribution panels are designed to optimize space utilization, making them suitable for installations where space is limited.
Energy Efficiency: Our panels are designed to maximize energy efficiency by minimizing power losses and optimizing load distribution, contributing to reduced operational costs and environmental impact.
Compliance and Certification: Our outdoor distribution panels comply with relevant industry standards and certifications, ensuring adherence to safety and performance requirements.
Comprehensive Support Services: We provide comprehensive support services, including design consultation, installation, commissioning, and ongoing technical support.
Our team of experts is committed to ensuring the reliable performance and longevity of your outdoor distribution panel boards.
For more information on our Outdoor Distribution Panel Boards and how they can meet your outdoor power distribution needs, please contact us or visit our contact page.
| General Overview |
|---|
| Electrical Specifications | |
|---|---|
| Rated Voltage | Up to 415V AC, 50/60 Hz |
| Rated Current | Up to 4000A |
| Short Circuit Rating | 50kA for 1 second |
| Busbar Material | Electrolytic grade copper/aluminum |
| Busbar Configuration | Three-phase and neutral with Earth |
| Insulation Level | 1000V AC |
| Cable Entry | Top/bottom entry as per customer requirements |
| Internal Wiring | PVC insulated copper cables |
| Protection Class | IP55 (Outdoor), IP65 (Indoor) |
| Mechanical Specifications | |
|---|---|
| Enclosure Material | CRCA (Cold Rolled Close Annealed) sheet steel |
| Panel Thickness | Doors: 2.0 mm Side Panels: 1.6 mm Base: 3.0 mm |
| Finish | Powder-coated with epoxy polyester |
| Color | RAL 7032 (or as specified by the customer) |
| Mounting | Floor standing with mounting bolts |
| Dimensions | Customizable as per requirement |
| Components | |
|---|---|
| Circuit Breakers | MCCBs (Molded Case Circuit Breakers) / ACBs (Air Circuit Breakers) |
| Fuse Units | HRC (High Rupturing Capacity) fuse units |
| Switches | Isolators and changeover switches |
| Indicators | LED type phase indication lamps |
| Meters | Digital multifunction meters for voltage, current, power, and energy |
| Surge Protection Devices | SPD for transient voltage protection |
| Terminals | Heavy-duty terminal blocks |
| Environmental Conditions | |
|---|---|
| Ambient Temperature | -5°C to +50°C |
| Relative Humidity | Up to 95% non-condensing |
| Installation Altitude | Up to 2000 meters above sea level without deratingg |
| Standards and Compliance | |
|---|---|
| Design and Construction | IEC 61439-1 & 2 |
| Degree of Protection | IEC 60529 |
| Short Circuit Rating | IEC 60947-2 |
| Type Tests | Temperature rise, short circuit withstand, dielectric strength, and degree of protection tests |
| Safety Features | |
|---|---|
| Interlocks | Mechanical and electrical interlocks to prevent unauthorized access |
| Earthing | Proper earthing for safety and protection against electrical faults |
| Lockable Doors | Provision for padlocking to ensure security |
| Gland Plates | Removable gland plates for easy cable termination |
| Labelling & Warning Labels | |
|---|---|
| Engraving Name Plates | Durable, engraved nameplates for clear component identification and panel labeling. |
| Warning Labels | Prominently displayed warning labels for high voltage, arc flash hazards, and operational cautions as per relevant safety standards. |
| Additional Features | |
|---|---|
| Anti-condensation Heaters | To prevent moisture accumulation |
| Ventilation | Louvers with filters for proper air circulation |
| Cable Management | Cable trays and cleats for organized cable routing |
| Documentation | Comprehensive user manual with wiring diagrams and installation instructions |
| Customization Options | |
|---|---|
| Enclosure Material | Stainless steel for corrosive environments |
| Finish | Custom colors and finishes |
| Components | Specific brands and types of electrical components as per customer preference |
| Control Options | Integration with SCADA systems for remote monitoring and control |
These specifications ensure that the Outdoor Distribution Panel Boards by Invent Controls are durable, weather-resistant, and capable of providing safe and efficient power distribution in diverse outdoor environments, meeting the stringent requirements of modern electrical installations.
Outdoor Distribution Boards by Invent Controls play a crucial role in electrical power distribution and management in outdoor environments across various industries. Here are the key industry applications where these distribution boards are extensively used:
Outdoor Distribution Boards from Invent Controls are designed to withstand harsh outdoor conditions while ensuring safe and reliable electrical power distribution. They are tailored to meet specific industry needs, incorporating advanced features for enhanced performance, durability, and operational efficiency in outdoor environments.
