What is Solar Distribution Panels?
Solar Distribution Panel Boards are essential components in solar power systems, designed to manage and distribute electricity generated by solar panels. These boards serve as the central hub for electrical circuits, ensuring the safe and efficient delivery of solar power to various loads or the main electrical grid. They typically feature multiple circuit breakers and protective devices to safeguard against overloads, short circuits, and other electrical faults. Solar distribution panel boards are engineered to handle direct current (DC) from solar arrays and may include inverters to convert DC to alternating current (AC) for household or commercial use. Their robust construction, often with a high IP rating, ensures durability and reliability in various environmental conditions, making them a critical component in maximizing the efficiency and safety of solar energy systems.
Solar Distribution Panel Boards @ Invent
At Invent Controls Private Limited, our Solar Distribution Panel Boards are meticulously designed to optimize the performance and safety of solar power systems. These panels serve as the critical interface between the solar power source and the electrical grid, ensuring efficient distribution and management of solar energy. Engineered with high-quality components and advanced technology, our Solar Distribution Panel Boards offer superior reliability, durability, and performance. Each panel is equipped with multiple safety features, including overcurrent protection, surge protection, and isolation switches, providing robust safeguarding against electrical faults and enhancing the longevity of your solar power installation.
Our Solar Distribution Panel Boards are designed to cater to a wide range of applications, from residential solar power systems to large-scale commercial and industrial installations. The panels are housed in rugged enclosures with a high IP rating, ensuring protection against dust, water, and other environmental factors. Additionally, the panels are powder-coated for enhanced corrosion resistance, making them ideal for outdoor installations. With a focus on user-friendly design, our panels offer easy installation and maintenance, featuring clear labeling and accessible components. Trust Invent Controls Private Limited for your solar distribution needs, and experience the perfect blend of innovation, quality, and performance
Special Features
Special Features of Invent Controls Solar Distribution Panel Boards
Enhanced Safety and Protection
Integrated Surge Protection Devices (SPD): Safeguards against transient overvoltages caused by lightning or other power surges.
Short Circuit and Overload Protection: Advanced circuit breakers to prevent damage and ensure the safety of the solar distribution system.
IP65/IP66 Rating: Dust-tight and water-resistant enclosures for both indoor and outdoor installations.
2. High Efficiency and Reliability
High-Quality Components: Use of premium quality materials and components to ensure durability and reliable performance.
Low Power Loss: Optimized design to minimize power loss and improve overall system efficiency.
Thermal Management: Effective heat dissipation mechanisms to maintain optimal operating temperatures and prevent overheating.
3. Easy Installation and Maintenance
Pre-wired and Pre-tested: Panels come pre-wired and tested, reducing on-site installation time and effort.
Modular Design: Easy to expand and adapt to changing requirements with a modular panel design.
Clear Labeling and Documentation: Each component is clearly labeled, and comprehensive documentation is provided for easy reference.
4. Advanced Monitoring and Control
Remote Monitoring Capabilities: Integration with IoT technology to enable real-time remote monitoring and control of the solar distribution system.
Data Logging and Reporting: Built-in data logging features to track performance metrics and generate reports for analysis.
User-Friendly Interface: Intuitive interfaces for easy system monitoring and control, accessible via web or mobile applications.
5. Customization and Flexibility
Tailor-Made Solutions: Customizable to meet specific project requirements and configurations.
Flexible Cable Entry Options: Multiple cable entry points to accommodate various installation scenarios and simplify wiring.
Scalable Design: Can be scaled up or down based on the size and capacity of the solar power system.
6. Environmental and Aesthetic Considerations
Eco-Friendly Materials: Use of environmentally friendly and recyclable materials in panel construction.
Compact and Aesthetic Design: Space-saving design with an aesthetically pleasing appearance, suitable for various installation environments.
UV Resistant Coating: UV-resistant powder coating to ensure long-term durability and appearance, even in harsh sunlight conditions.
7. Compliance and Certification
International Standards: Compliance with international standards such as IEC, UL, and CE for safety and performance.
Quality Assurance: Rigorous quality control processes to ensure each panel meets the highest standards before delivery.
Warranty and Support: Comprehensive warranty and after-sales support to ensure customer satisfaction and peace of mind.
These special features make Invent Controls Solar Distribution Panel Boards a reliable, efficient, and user-friendly solution for managing solar power distribution in various applications.
| General Overview |
Solar Distribution Panels are essential components in electrical distribution systems, providing a centralized point for controlling and distributing electrical power. These panels are designed to accommodate various electrical components, ensuring reliable power distribution for industrial, commercial, and residential applications.
| Electrical Specifications |
| Rated Voltage |
Up to 415V AC, 50/60 Hz |
| Rated Current |
Up to 4000A |
| Short Circuit Rating |
50kA for 1 second |
| Busbar Material |
Electrolytic grade copper/aluminum |
| Busbar Configuration |
Three-phase and neutral with Earth |
| Insulation Level |
1000V AC |
| Cable Entry |
Top/bottom entry as per customer requirements |
| Internal Wiring |
PVC insulated copper cables |
| Protection Class |
IP55 (Outdoor), IP65 (Indoor) |
| Mechanical Specifications |
| Enclosure Material |
CRCA (Cold Rolled Close Annealed) sheet steel |
| Panel Thickness |
Doors: 2.0 mm
Side Panels: 1.6 mm
Base: 3.0 mm
|
| Finish |
Powder-coated with epoxy polyester |
| Color |
RAL 7032 (or as specified by the customer) |
| Mounting |
Floor standing with mounting bolts |
| Dimensions |
Customizable as per requirement |
| Components |
| Circuit Breakers |
MCCBs (Molded Case Circuit Breakers) / ACBs (Air Circuit Breakers) |
| Fuse Units |
HRC (High Rupturing Capacity) fuse units |
| Switches |
Isolators and changeover switches |
| Indicators |
LED type phase indication lamps |
| Meters |
Digital multifunction meters for voltage, current, power, and energy |
| Surge Protection Devices |
SPD for transient voltage protection |
| Terminals |
Heavy-duty terminal blocks |
| Environmental Conditions |
| Ambient Temperature |
-5°C to +50°C |
| Relative Humidity |
Up to 95% non-condensing |
| Installation Altitude |
Up to 2000 meters above sea level without deratingg |
| Standards and Compliance |
| Design and Construction |
IEC 61439-1 & 2 |
| Degree of Protection |
IEC 60529 |
| Short Circuit Rating |
IEC 60947-2 |
| Type Tests |
Temperature rise, short circuit withstand, dielectric strength, and degree of protection tests |
| Safety Features |
| Interlocks |
Mechanical and electrical interlocks to prevent unauthorized access |
| Earthing |
Proper earthing for safety and protection against electrical faults |
| Lockable Doors |
Provision for padlocking to ensure security |
| Gland Plates |
Removable gland plates for easy cable termination |
| Labelling & Warning Labels |
| Engraving Name Plates |
Durable, engraved nameplates for clear component identification and panel labeling. |
| Warning Labels |
Prominently displayed warning labels for high voltage, arc flash hazards, and operational cautions as per relevant safety standards. |
| Additional Features |
| Anti-condensation Heaters |
To prevent moisture accumulation |
| Ventilation |
Louvers with filters for proper air circulation |
| Cable Management |
Cable trays and cleats for organized cable routing |
| Documentation |
Comprehensive user manual with wiring diagrams and installation instructions |
| Customization Options |
| Enclosure Material |
Stainless steel for corrosive environments |
| Finish |
Custom colors and finishes |
| Components |
Specific brands and types of electrical components as per customer preference |
| Control Options |
Integration with SCADA systems for remote monitoring and control |
These specifications ensure that the Solar Distribution Panels by Invent Controls are robust, reliable, and suitable for a wide range of electrical distribution applications, providing optimal performance and safety.
